1, Material:
<1> Inner tank: Imported SUS304-2B food-level stainless steel,thickness:1.0~1.5mm
<2> Outer tank: High quality galvanized steel,thickness:0.31~0.5mm
<3> Insulation: 50~55mm polyurethane foam
<4> Solar panel: Eta plus coating or black chrome coating
<5> Frame: Coated steel/Aluminum alloy,thickness:1.2~2mm
<6> Reflector: Stainless steel/Aluminum alloy as option
<7> Available accessories: Solar controller,electric heater,Safety Valve,Mag rod,thermostatic mixing valve
2, Size range:
| ITEM.NO | SPECIFICATION | EFFECTIVE LIGHT AREA | TANK'S CAPACITY | APPLICATION PEOPLE | CBM | |||
| DIAMETER OF WATER TANK | PANEL | PANEL SIZE | ||||||
| Z-PC100F | 460mm | 1 | 2000*1000*80mm | 2 | 100L | 4 | 0.42 | |
| Z-PC150F | 460mm | 1 | 2000*1250*80mm | 2.5 | 150L | 6 | 0.59 | |
| Z-PC200F | 460mm | 2 | 2000*800*80mm | 3.2 | 200L | 8 | 0.73 | |
| Z-PC250F | 460mm | 2 | 2000*1000*80mm | 4 | 250L | 10 | 0.96 | |
| Z-PC300F | 460mm | 2 | 2000*1250*80mm | 5 | 300L | 12 | 1.07 | |
| Z-PC350F | 460mm | 2 | 2000*1250*80mm | 5 | 350L | 14 | 1.2 | |
